RF Innovation

FEATURED PRODUCTS

High-Performance RF Solutions Engineered for Efficiency

Our RF solutions deliver high output power, low noise figures, low current consumption, and superior efficiency to meet the most demanding system requirements. Engineered to maximize performance while minimizing power consumption and system costs, our portfolio offers an exceptional performance-to-value advantage.

Featured High-Performance Products:

  • RFPAF01S – 300 MHz–1 GHz Power Amplifier with 16 dB Gain, 22 dBm Output Power (Pout), 1.5 dB Noise Figure, and 43 mA current consumption.
  • RFPA5.8S – 5.5–6 GHz Power Amplifier with 23 dB Gain and 30 dBm Output Power (Pout)
  • RFLN07S – 2–7 GHz Low Noise Amplifier with 26 dB Gain, a 0.8 dB Noise Figure (3–5 GHz), and 48mA current consumption.
  • RFLN28 – 26–30 GHz Low Noise Amplifier with 24 dB Gain. RFLN40C – Reverse Gain Slope Amplifier covering 20–40 GHz.

OUR SAMPLE READY PRODUCTS (AMPLIFIERS AND ATTENUATORS)

Sr. No Part Name Function Frequency (GHz) Gain (dB) Noise Figure (dB) P1dB (dBm) For More Details
1 RFDA06 DRIVER AMPLIFIER 2-6 GHz 24 1.5 23.5 Click Here
2 RFPA06 POWER AMPLIFIER 2-6 GHz 23 - 25 Click Here
3 RFLNAM12 LOW NOISE AMPLIFIER 8-12 GHz 22.5 1.78 17.8 Click Here
4 RFDA20 DRIVER AMPLIFIER 2-20 GHz 17 3.14 17.4 Click Here
5 RFDVA30 DIGITAL VARIABLE ATTENUATOR DC to 32 GHz Attenuation = 0.9 to 9 dB Click Here
6 RFDAAM18 DRIVER AMPLIFIER 12-18 GHz 13 2.3 19.7 Click Here
7 RFDCA20 DIRECT COUPLED AMPLIFIER DC-20 GHz 14 - 5.8 Click Here
8 RFSWHP20 SPDT SWITCH 2-20 GHz Insertion Loss (dB) Isolation (dB) IP1dB (dBm) Click Here
1.1 54 28.2
For more products - Click here
