RF LOW NOISE AMPLIFIERS

Our RFIC MMIC low noise amplifiers(LNAs) are designed for exceptional performance across various frequency bands, including 2 to 7 GHz, Ku-band and X-band. Ideal for applications in satellite communications, radar systems and electronic warfare, these solid-state amplifiers feature a remarkable low noise figure of just 0.4 dB and deliver significant gain.

FABRICATED RF LOW NOISE AMPLIFIERS

Sr. No. Part Name Function Frequency (GHz) Gain (dB) Noise Figure (dB) P1dB (dBm) For More Details
1 RFLN07S Small Die Low Noise Amplifier 2 to 7 27 0.7-0.9 10.8 Click Here
2 RFTLN20 Low Noise Amplifier 12 to 20 14.3 2.3 21.2 Click Here
3 RFLN28 Low Noise Amplifier 24 to 28 24.5 1.8 15 Click Here
4 RFGLN28 GaAs On Glass Low Noise Amplifier 24 to 28 12.9 2.8 17.9 Click Here
5 RFLN08S Low Noise Amplifier 2-8 GHz 20 1.9 - Click Here

UNDER – DEVELOPMENT LOW NOISE AMPLIFIERS

Sr. No. Part Name Function Frequency (GHz) Gain (dB) Noise Figure (dB) P1dB (dBm) For More Details
6 RFLN04 Low Noise Amplifier 2 to 4 28 1.2 11.4 Click Here
7 RFLN06 Low Noise Amplifier 2 to 6 32 1.2 20 Click Here
8 RFTLN12 Low Noise Amplifier 1 to 12 25 2 to 2.5 - Click Here
9 RFLN12 Self Bias Low Noise Amplifier 8 to 12 19.1 1.8 12 Click Here
10 RFLNAM18 Low Noise Amplifier 12 to 18 21 1.7 21 Click Here
11 RFLN18 Low Noise Amplifier 12 to 18 16.7 1.9 9.16 Click Here
12 RFLN18D Low Noise Amplifier 12 to 18 25 1.2 16.2 Click Here
13 RFLN30 Low Noise Amplifier 24 to 30 25.5 1.3 16 Click Here
14 RFLN30R Low Noise Amplifier 18 to 30 22 2.2 15 Click Here
15 RFLN06A Low Noise Amplifier 20 to 40 20 2.8 20.5 Click Here
16 RFLN123 Low Noise Amplifier 122 to 123 12 11.5 - Click Here
17 RFLN40A Low Noise Amplifier 20-40 GHz 26 - 15 Click Here
18 RFLN40A_B Low Noise Amplifier 20-40 GHz 19 4 - Click Here

Applications of RFIC/MMIC LNAs

– Satellite Communications
– Radar Systems
– Electronic Warfare
– Telecommunications
– Remote Sensing
– WIFi-6E/7
